PRODUCT DESCRIPTIONS

DISRUPTIVE TECHNOLOGY INNOVATIONS

For Electric Car

Items

Details

Battery Type

NMC

Rated Capacity

100Ah

Rated Voltage

144V

Energy

14.4kW

Weight

130.91kg

Number of Cycle

≥1,500 @1C, DOD 100%

Array

40S2P

Operating Temperature

Charging 0℃~55℃
Discharging -20℃~55℃

Items

Details

Battery Type

Lifepo4

Rated Capacity

210Ah

Rated Voltage

345.6V

Energy

72.57kW

Weight

518.4kg

Number of Cycle

≥1,500 @1C, DOD 100%

Array

108S2P

Operating Temperature

Charging 0℃~55℃
Discharging -20℃~55℃

Items

Details

Battery Type

NMC

Rated Capacity

200Ah

Rated Voltage

96V

Energy

19.2kW

Weight

140.7kg

Number of Cycle

≥1,500 @1C, DOD 100%

Array

27S4P

Operating Temperature

Charging 0℃~55℃
Discharging -20℃~55℃

Items

Details

Battery Type

NMC

Rated Capacity

150Ah

Rated Voltage

328.5V

Energy

49.27kW

Weight

351.9kg

Number of Cycle

≥1,500 @1C, DOD 100%

Array

90S3P

Operating Temperature

Charging 0℃~55℃
Discharging -20℃~55℃
